1055nm BPF
料號：BF0-KQAGA-1055
產品規格
| Parameters | Specification | Unit |
| Angle of Incident | 0 | degree |
| Beam type | Collimation | |
| Wavelength in Pass Band | 1052.5-1057.5 | nm |
| Wavelength in Reflection Band | 1000-1047.5 & 1062.5-1100 | nm |
| Max Insertion Loss in Pass Band | <0.25 | dB |
| Isolation | >30 | dB |
| Operation Temperature | -40 ~ +85 | ℃ |
| Size | Customized | mm |
| Wedge | >0.1 | degree |
| Damage Threshold | >20 | KW/cm2 |
