產品介紹
光通被動濾片
XGS-PON, T 1270+1564 / R 1310+1490+1625
料號：DB0-XMA7D-2667
產品規格
| Parameters | Unit | Specifications |
| Operation Wavelength | nm | 1260~1650 |
| Angle of Incident | degree | 1.8 |
| Pass Band Width | nm | 1260~1280& 1524~1603 |
| Stop Band Width | nm | 1290-1500 &1615(1610)~1670 |
| Transmission Isolation | dB | >=30 |
| Max IL within PassBand | dB | <=0.3 |
| Ripple within PassBand | dB | <= 0.2 |
| Reflection Isolation | dB | >=13 or 15 |
| Max IL within StopBand | dB | <=0.2 |
| Ripple within StopBand | dB | <=0.15 |
| Polarization Dependent Loss within PassBand | dB | <= 0.1 |
| Reflection of Backside AR Coating | % | <= 0.2 |
| Size (Length ´ Width ´ Thickness) | mm | (1.4+/-0.1) ´ (1.4+/-0.1) ´ (0.9~1.4) |
| Wedge Angle | degree | 0.2 |
| Edge/Corner Chip | mm | <= 0.1 |
| Scratch/Dig | 40 / 20 |
