光通被動濾片
G-PON 1310+1490 RISO30dB
料號：BF0-1ABFA-2950
產品規格
| G-PON, 1310+1490, RISO30dB | ||
| Parameters | Unit | Specifications |
| Operation Wavelength | nm | 1260~1650 |
| Angle of Incident | degree | 1.8 |
| Pass Band Width | nm | 1300-1330,1480-1500 |
| Stop Band Width | nm | 1260-1280,1524-1650 |
| Transmission Isolation | dB | >= 30 |
| Max IL within PassBand | dB | <= 0.3 |
| Ripple within PassBand | dB | <= 0.2 |
| Reflection Isolation | dB | >= 30 |
| Max IL within StopBand | dB | <= 0.2 |
| Ripple within StopBand | dB | <= 0.15 |
| Polarization Dependent Loss within PassBand | dB | <= 0.1 |
| Reflection of Backside AR Coating | % | <= 0.2 |
| Size (Length * Width * Thickness) | mm | (1.4+/-0.1) * (1.4+/-0.1) * (1.0+/-0.2) |
| Wedge Angle | degree | 0.2 |
| Edge/Corner Chip | mm | <= 0.1 |
| Scratch/Dig | 40 / 20 | |
