光通被動濾片
FWDM-1310+1490+1550/1610, RISO30
料號：ED0-CBD7D-2567
產品規格
| 1310+1490+1550 / 1610 FWDM Filter, RISO30 | ||
| Parameters | Unit | Specifications |
| Operation Wavelength | nm | 1260~1670 |
| Angle of Incident | degree | 1.8 |
| Pass Band Width | nm | 1260~1580 |
| Stop Band Width | nm | 1600~1670 |
| Transmission Isolation | dB | >=40 |
| Max IL within PassBand | dB | <=0.3 |
| Ripple within PassBand | dB | <=0.2 |
| Reflection Isolation | dB | >=30 |
| Max IL within StopBand | dB | <=0.2 |
| Ripple within StopBand | dB | <=0.15 |
| Polarization Dependent Loss within PassBand | dB | <=0.1 |
| Reflection of Backside AR Coating | % | <=0.2 |
| Size (Length*Width*Thickness) | mm | (1.4+/-0.1)*(1.4+/-0.1)*(1.0+/-0.2) |
| Wedge Angle | degree | 0.2 |
| Edge/Corner Chip | mm | <=0.1 |
| Scratch/Dig | 40 / 20 | |
